FNIRSI-1014D Digital Oscilloscope | Everything You Need To Know!
FNIRSI-1014D
is a two in one oscilloscope and signal generator launched by FNIRSI.
It has comprehensive functions and high practicability. It is a
cost-effective dual channel desktop oscilloscope for the maintenance
industry and R & D industry.
FNIRSI 1014D
is a 100 MHz bandwidth dual-channel oscilloscope with a built-in
waveform generator. The oscilloscope features a high real-time sampling
rate of 1 GS/s, 240 kB memory, a large 7-inch display with 800 × 480
resolution, and advanced features for capturing, analyzing, and
recording measurement results.
Besides, the device features high
voltage protection, which ensures safe operation with signals up to 400
V. Built-in generator generates 14 types of signals, voltage resolution
is 8 bit, voltage 5 Vpeak-peak.
FNIRSI 1014D is equipped with a
USB interface to connect to the computer. This oscilloscope is designed
for diagnostics and tuning of radio and electronic equipment.
The
oscilloscope has a real-time sampling rate of 1GSa / s and 100MHz* 2
analog bandwidth; complete trigger function (single time / normal /
automatic), both for periodic analog signal and aperiodic digital signal
can be used freely;
Built in DDS function signal generator and
the industry's original chopping output (@ 2.5vpp), all signal frequency
step is 1Hz, support 14 kinds of standard function signal and a
customizable chopping signal, chopping.
The output device
intercepts part or the whole part of the complex signals measured by the
oscilloscope as the output signal of the signal generator, which can
store up to 1000 customized cut-off signals; the built-in high-voltage
protection module can tolerate up to 400V continuous voltage, without
worrying about the oscilloscope burning accident caused by the probe not
moving to 10x gear.
Large
time base scrolling mode, which can monitor slow level changes;
equipped with efficient one button auto, which can display the measured
waveform without tedious adjustment; display high-definition LCD with
7-inch 800 * 480 resolution; cursor measurement function, when manually
reading amplitude and frequency parameters, it does not need to read the
background scale unit and quantity, and it does not need to convert to
directly get peak to peak and frequency Extremely convenient screen
capture and waveform storage function.
Built-in 1GB storage space,
can store up to 1000 screen capture pictures + 1000 groups of waveform
data, the storage process is simple and fast, save the current waveform
with only one click, no cumbersome prompts and choices to save the
current data, very convenient; powerful waveform image manager, support
thumbnail browsing, view, view details
The functions of page
turning, deleting and waveform enlarging, reducing and moving are
convenient for secondary analysis. The fuselage is equipped with USB
interface, which can be connected with the computer to realize the
sharing of its own screen capture pictures and the computer, which is
convenient for secondary analysis;
Li
Shayu's graphic display function can be used to compare and judge the
amplitude, frequency and phase of two groups of signals; FFT viewing
function can estimate the harmonic component of signals; Li Shayu's
graphic display function can be used to compare and judge the amplitude,
frequency and phase of two groups of signals.
